| Part No. Series |
Size/Fits Chip (mm) |
Heatsink Height (mm) |
Fin Tip to Fin Tip(mm) |
weight (g) |
Thermalresistance(C/W) |
| Natural Convection |
200LFM |
400LFM |
600LFM |
| MBH35002-26PR/2.6 |
35x35 |
25.6 |
(34.6)x(34.6) |
21.2 |
6.0 |
1.81 |
1.23 |
1.02 |
| MBH35002-33PR/2.6 |
35x35 |
32.6 |
(36.5)x(36.5) |
25.0 |
5.5 |
1.48 |
1.03 |
0.78 |
| MBH37.5002-26PR/2.6 |
37.5x37.5 |
25.6 |
(37.1)x(38.5) |
25.8 |
5.7 |
1.68 |
1.11 |
0.86 |
| MBH37.5002-33PR/2.6 |
37.5x37.5 |
32.6 |
(39.2)x(40.5) |
30.7 |
5.2 |
1.37 |
0.93 |
0.65 |
| MBH40002-26PR/2.6 |
40x40 |
25.6 |
(39.3)x(41.1) |
29.1 |
5.4 |
1.57 |
1.02 |
0.75 |
| MBH40002-33PR/2.6 |
40x40 |
32.6 |
(41.3)x(43.1) |
34.6 |
5.0 |
1.25 |
0.86 |
0.60 |
| MBH42.5002-26PR/2.6 |
42.5x42.5 |
25.6 |
(43.4)x(43.7) |
34.3 |
5.2 |
1.43 |
0.89 |
0.68 |
| MBH42.5002-33PR/2.6 |
42.5x42.5 |
32.6 |
(45.8)x(46.1) |
40.8 |
4.8 |
1.02 |
0.67 |
0.47 |
|
